- Remove any heat-treated scales that are on the surface of the plates.
- Rust Elimination
- for de-painting ship metal surfaces and structural steel components.
- for roughening up surfaces so that paint or primer will adhere properly.
- For the automobile industry, Plate Cleaning Shot Blasting Machines are primarily used for welding slag removal, steel plate stress elimination, fault detection, and anti-rust treatment.
- Plate Cleaning Shot Blasting Machine is used for releasing rust & scale from Scaffoldings, and structural steels like angles, channels, and beams which are used widely in the building industry.
Leading Supplier & Exporter
Trustseal Verified
ISO Certified
Manufacturer
Plate Cleaner Shot Blasting machine
Plate Cleaning Shot Blasting Machine consists of various centrifugal blast wheels each of them driven by individual motors to give a thorough cleaning. The jobs are kept on a suitable conveying system with varying velocities flexible according to the working environment. The job enters the Shot blasting cabinet for cleaning from abrasive material also known as media fired by multi wheels for providing homogeneous finishing. All shot-blasted components come out from the exit of the cabinet.
Plate Cleaning Shot Blasting machines are adequately equipped with abrasive media recovery and Dust Collector, cleaning systems, control panels, and rubber, or other material lining to handle the wear of the machine. Plate Cleaning Shot Blasting Machine for sale in India at a low price with the best quality. Airo Shot Blast is the best shot blasting machine Manufacturers of portable shot blasting machine, automatic shot blasting machine, tumblast shot blasting machine, stone shot blaster machine, cabinet shot blasting machine for sale in Jodhpur, Rajasthan, India.
Plate Cleaning Shot Blasting Machine Specification
| No. of Blast Wheel | 2 |
| No. of Blades (each wheel) | 8 |
| Size of Blast Wheel | 50R210 |
| Horse Power of Blast Wheel | 100 HP, Qty – 02 Nos. |
| R.P.M. of Blast Wheel | 1850 |
Plate Cleaning Shot Blasting Machine Abrasive Flow :
| Approx. Shots flow rate | 700 Kg /minute |
| Shot Velocity | 70-80 Mtrs./Sec. |
| Shots Consumption rate | 0.13 kg/hp/ hr |
| Initial Charge of Shots | 4000 Kg. (to be provided by purchaser) |
Plate Cleaning Shot Blasting Machine Recovery System
| Drive For Bucket Elevator | 15HP |
| Drive For Screw Conveyor (total) | 7.5Hp |
| Skew Roller Conveyor Systems | Upto 2mtr/min |
| Length of the conveyor (inlet) | 10000 mm |
| Length of the conveyor (outlet) | 13000 mm |
| Compressed Air requirement at 6 Kg/cm2 pressure | 25 CFM AT 7 Kg./cm2 |
| Dust collector System | Vibratory Shaking type |
| The capacity of the dust collector | 15000 CFM |
| Filter cloth area | 316 sq mtr |
| No of bags | 300 nos |
| Bag Type | Fabric Bags |
| Gear Motor | 04 nos |
| HP of geared motor | 1.0 HP each |
| Bag Cleaning | Vibratory Shaking type through the sequential timer |
| Noise Level | 80-85 dB (A) at 3 Mtr. From Machine. |
| Cleaning Standard | SA 2.5-3 |
| Job Movement | Rotational with linear movement |
| Control Panel | Centralized Cubical type panel |
Plate Cleaning Shot Blasting Machine Dimensions
| Overall Dimension of pipe blasting machine Or pipe descaling equipment |
Length 28000mm Width 8500mm Height 6300mm(GL) |
| Floor Space required for Machine without Reverse Pulse Jet Type Dust Collector |
Length 28000mm Width 9000mm |
| Pit Requirement of pipe descaling equipment | Length 6000mm Width 3500mm Depth 1300mm |
| Total Power Require | 268.5 HP(200 kW) |
| Blast Wheel 100 HP x 2 | 200.0 |
| Bucket Elevator 15 HP x 1 | 15.0 |
| Upper Screw Conveyor 7.5 HP x1 | 7.5 |
| Inlet Conveyor 1 HP x 3 | 3.0 |
| Outlet Conveyor 1 HP x 3 | 3.0 |
| Dust Collector 40 HP | 40 |
Plate Cleaner Blasting Machine
The Sand / Shot Blasting Cabinet is lined with High Manganese Tiles in an overlay style for easy replacement if any problem occurs. For protection purposes, the perforated manganese cast sheet is placed above the screw conveyor line. Various Shot Blast rubber screens are given in the inlet and outlet Vestibules to quit escaping abrasive material from the machine. The Rollers are set with replaceable High Manganese Steel inside the Blast Cabinet.
During the Safety features, setting Doors are given in Blast Cabinet. When the job is in Shot Blasting Cabinet to avoid unnecessary blasting of the job, the Sensor is provided at Vestibules for starting Blast Cycle. To cover Shot Blasting of end faces of fabricated elements blast Wheel 4 Nos. / 6 Nos. are fitted in the Blast Cabinet. For transferring shots to the Rotary Screen Separator a suitable capacity Elevator is used and it can be customized according to the need of the customer. The Rotary Screen Separator cleans the abrasive media and removes oversized as well as dust particles and only particular-sized Shots are allowed to insert in the Blasting Wheels.
Working of Plate Cleaning Shot Blasting Machine
All Blast Wheel Stations are having an installed type shot valve for regulating the quantum of shots to the blast wheel system. A dust collector of reverse pulse jet type is designed and used for the continuous heavy-duty operation of the Plate Cleaning Shot Blasting Machine. The main function of Dust Collector is to keep Blast Cabinet ventilated and eliminate dust particles flying in the cabinet and differentiate small-sized shots from abrasive media which can’t be reused again. The operation of the entire plate shot blasting machine is sequentially programmed by PLC mounted in Control Panel. The PLC shows the working status of a machine, which includes no. of Hours of Machine work for maintenance requirements and different Trouble Shooting demands. PLC Program can be made as per the Customer’s requirement.
Plate Cleaning Shot Blasting Machine Manufacturer
Airo Shot Blast is a Leading Plate Cleaning Shot Blasting Machine manufacturer in India at a low price. The cost of the Shot Blasting Machine in India depends on the production capacity and size of the job. We are is the leading Shot blasting machine manufacturer in India that offers the complete automatic grit blasting machine, Sand blasting machine, Shot blasting machine, and abrasive media with the R&D (Research & Development) at a low price.
